CAMERA CHUYÊN DỤNG : Camera Hikvision

Hybrid SAN DS-A82024D

  • Hãng sản xuất: Hikvision
  • Giá: Liên hệ
  • VAT: Chưa bao gồm VAT
  • Bảo hành: 24 tháng
  • Tình trạng: Còn hàng

24-slot High-performance Dual Controller Storage

  • Dual controller and real-time cache, optional BBU (Backup Battery Unit), one multi-core processor, 8 GB cache extendable to 32 GB per controller

  • High-performance, extendable hardware platform

  • HDD detection and repair/RAID optimization

  • Surveillance-specialized direct storage (Direct Streaming mode+IP SAN mode)

  • Advanced data protection (synchronous backup of key information in system disks)

  • Energy efficient and user-friendly UI



  • Network

  • ProtocoliSCSI, RTSP, ONVIF, PSIA

  • External Interface

  • USB3

  • VGA1

  • Data Network Interface4, 1000M Ethernet interface (4 × GbE or 2 × 10GbE is extendable)

  • Management1, 1000M Ethernet interface/Controller

  • MiniSAS InterfaceSupported

  • General

  • Power SupplyRedundant

  • Chassis19-inch 4U

  • Consumption(With HDDs)Working: ≤ 507 W (1729 BTU with 24 HDDs); Rated: ≤ 800 W

  • Environment TemperatureWorking: +5 °C to +35 °C (41 °F to 95 °F); Storing: -20 °C to +70 °C (-4 °F to 158 °F)

  • Humidity Working: 20% to 80%RH (non-condensing/frozen);   Storing: 5% to 90%RH (non-condensing/frozen)

  • Dimensions(W × D × H)447 x 172 x 550 mm (17.6 x 6.8 x 21.7 in)

  • Weight (Without HDDs)≤ 33.5 Kg (73.9 lb)

  • Storage

  • HDD Slot24

  • Interface/CapacitySSD (optional), SAS/1TB, 2TB, 3TB, 4TB, 6TB,8TB,10TB,12TB

  • Hot-SwappingSupported

  • HDD SupportSingle, RAID(Enterprise Hard Disk)

  • RAIDRAID0, 1, 3, 5, 6, 10, 50, JBOD, Hot-Spare

  • Performance

  • Direct Streaming Mode: Video (2 Mbps) + Picture448-ch (recording + playback)

  • IPSAN Mode256-ch (recording + playback)

  • Hardware

  • StructureDual controller

  • Processor64-bit multi-core processor

  • Cache8 GB (extendable to 32 GB)/controller

  • Storage Management

  • Disk ManagementDisk inspection, alarm and repair

  • Logical Volume ManagementiSCSI volume, video volume management

  • Recording Management

  • Recording ModeTiming recording, manual recording, dual-stream recording, alarm recording

  • Video ProtectionLock key video, N+1 service protection, ANR, video loss detection and alarm

  • Searching ModeSearch by time and event

  • Downloading ModeQuick download, batch download, download by segment, download by merging

  • Device Maintenance

  • Management ModeWeb-based GUI, serial port CLI, centralized management of multiple devices

  • Alarm ModeSound, light, email, message, web page

  • Log DownloadingDownload no web page
